3D Models
We design every van using 3D modeling software. In doing so, we’ve created detailed models of each van to plan and design on. We’re working on more models each week so, please check back often if your desired van isn’t available yet.
Parametrically modeled off a 2021 Sprinter 144 chassis (not a lidar scan)
All factory holes are shown and located to within .25"
Great for getting quick reference dimensions, but use caution, as things might not be 100% spot on (1/4" accuracy)
Also great for determining how to position items for easy mounting with respect to the van structure
There are free online .stp file viewers available here: https://viewer.autodesk.com/
.stp and .stl files provided
This model is of the cargo area only. Images depicted with cabinetry and components are for artistic reference only.
Printable Sketch Templates
We’ve created sketch templates that we use to design custom vans for our clients. Download and print to start dreaming up the layout and features Download a watermarked sample here.
Mercedes Sprinter 144" High Roof - Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Ford Transit 148" Mid Roof - Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Mercedes Sprinter 1170" High Roof - Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Ford Transit 148" High Roof - Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Mercedes Sprinter 170" High Roof Extended - Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Ford Transit. 148” High Roof Extended- Scale sketch template design set. Print this planning tool on 8.5 x 11” paper and start designing your dream van. The template set includes the following views to help you plan your build:
Driver, Passenger, Front, Rear, Floorplan, and Roof.
Another great resource for your DIY Build is the Sprinter RV Conversion Sourcebook by Greg Keith. It’s packed with knowledge on all of the systems and components for your build.
Most of the information in this book can be used to build any model of van. ie Ford Transits, Ram Promasters, Nissan NV200 or any other cargo van.
